Description
Please see below for the Yamaha 450 specifications.
Yamaha YFZ450 General Information
|
|
Brand |
Yamaha |
|
Model |
Yamaha YFZ450 |
Yamaha YFZ450 Dimensions, Aerodynamics and weight
|
|
Frame type |
– |
|
Seat details |
– |
|
Wheelbase |
1,280 mm (50.4 inches) |
|
Length |
1,839 mm (72.4 inches) |
|
Width |
1,171 mm (46.1 inches) |
|
Height |
– |
|
Seat Height |
810 mm (31.9 inches) If adjustable, lowest setting. |
|
Alternate Seat Height |
– |
|
Ground Clearance |
114 mm (4.5 inches) |
|
Trail size |
– |
|
Wheels details |
– |
|
Front Tyres – Rims dimensions |
21/7-10 |
|
Rear Tyres – Rims dimensions |
20/10-9 |
|
Front brakes |
Double disc. Hydraulic disc |
|
Rear brakes |
Single disc. Hydraulic Disc |
|
Front Brakes Dimensions – Disc Dimensions |
127 mm (5.0 inches) |
|
Rear Brakes Dimensions – Disc Dimensions |
173 mm (6.8 inches) |
|
Curb Weight (including fluids) |
172.8 kg (381.0 pounds) |
|
Dry Weight |
– |
|
Front Percentage of Weight |
– |
|
Rear Percentage of Weight |
– |
|
Weight-Power Output Ratio : |
– |
|
Fuel Tank Capacity |
9.84 litres (2.60 gallons) |
|
Reserve Fuel Capacity |
– |
|
Carrying Details and Capacity |
– |
|
Front Suspension |
Independent double wishbone, threaded preload adjustment, 9.1-in travel |
|
Front Suspension Travel |
– |
|
Rear Suspension |
Cast aluminum swing arm, threaded preload adjustment, 10.6-in travel |
|
Rear Suspension Travel |
– |
Yamaha YFZ450 Engine and Transmission Technical Data
|
|
Engine type – Number of cylinders |
Single cylinder, four-stroke |
|
Engine details |
Titanium valves |
|
Fuel system |
Carburettor. Mikuni 42mm BSR |
|
Engine size – Displacement – Engine capacity |
449.00 ccm (27.40 cubic inches) |
|
Bore x Stroke |
95.0 x 63.4 mm (3.7 x 2.5 inches) |
|
Compression Ratio |
11.4:1 |
|
Number of valves per cylinder |
– |
|
Camshaft Valvetrain Configuration |
DOHC |
|
Maximum power – Output – Horsepower |
– |
|
Maximum torque |
– |
|
Engine Maximum RPM |
– |
|
Cooling system |
Liquid |
|
Lubrication system |
– |
|
Engine oil capacity |
– |
|
Exhaust system |
– |
|
Gearbox |
5-speed |
|
Transmission type, final drive ratio |
Chain |
|
Clutch type |
Wet multiplate |
|
Driveline |
2WD; sealed O-ring chain, eccentric adjustment |
Yamaha YFZ450 Performance
|
|
Top Speed |
– |
|
Acceleration 0 to 100 km/h (0 to 62 mph) |
– |
|
Acceleration 0 to 400m (1/4 mile) |
– |
|
Recuperation 60 to 140 km/h in highest gear |
– |
|
Fuel Consumption – MPG – Economy – Efficiency |
– |
|
CO2 emissions |
– |
|
Emissions |
– |
Yamaha YFZ450 Electrical Systems, Ignition and Equipment
|
|
Ignition Type |
DC – CDI |
|
Electrical Details |
– |
|
Starter Type |
Electric |
|
Instruments |
– |
|
Lights |
Dual 30W Krypton multireflector headlights and 3.9/0.5W LED brakelight |
